BlueSolar PWM-Pro 12/24V

Product Code: BlueSolar PWM-Pro 12/24V

Victron Energy

Product Features

  • Battery Voltage: 12/24 Auto Select
  • Charging Current: 5A, 10A, 20A, 30A
  • Second Battery Output: No
  • Self Consumption: 6mA
  • Operating temperature: -20ºC to +50ºC
Show More

Charging Current

Please enquire
Product Description

Victron BlueSolar PWM-Pro Charge Controller 12/24V

Select charge rated curent: (5A, 10A, 20A or 30A)

Programmable
The BlueSolar PWM-Pro series is ready for use with its default settings.
It also is fully programmable:
- With help of a computer and software (available free of charge   from our website)
- With the dedicated BlueSolar Pro Remote Panel (see features below).

Features:
- Lighting control function, fully programmable.
- Three stage battery charging (bulk, absorption, float), fully programmable.
- Integrated battery monitor function (Remote Panel needed to display state of charge).
- Load output with low voltage disconnect and manual control (default setting).
- Optional external temperature sensor.
- Load output protected against over load and short circuit.
- Protected against reverse polarity connection of the solar array and/or battery.

Day/night timing options
See manual for details

    Product Specification
    Battery Voltage 12/24 Auto Select
    Charging Current 5A, 10A, 20A, 30A
    Second Battery Output No
    Self Consumption 6mA
    Operating temperature -20ºC to +50ºC
